SM24 - Coming Soon
A smart choice that delivers top performance at a reasonable cost.
The SM24 is a TCO-optimized device that focuses on essential functionality, delivering reliable performance with its 2.4GHz octa-core processor and support for Android 16–18 while keeping overall costs low.It's HD+ display and single scanner configuration reduce power consumption and complexity, greatly improving operational efficiency and lowering maintenance expenses.
In addition, Wi-Fi 6E, IP67 protection, and 1.8m drop resistance ensure stable operation even in harsh environments,
while 4000/6000mAh battery options and USB-C/POGO expandability support long shifts and diverse workflows maximizing long-term cost savings.
Highlights
-
Value-Oriented Performance
With its 2.4GHz octa-core processor and support for Android 16–18, the SM24 delivers modern performance while offering a more cost-efficient configuration compared to competing products making it highly favorable for TCO reduction and particularly suitable for budget-focused warehouse and retail customers. -
Enhanced Readability and Usability with a 6-inch HD+ Display
The HD+ (720×1440) display reduces power consumption to improve battery efficiency while lowering overall costs, providing an optimized viewing experience for lightweight, app-focused tasks such as inventory checks and inbound/outbound operations. -
Simplified and Reliable Operation with a Single Scanner Configuration
The single-scanner setup reduces decision complexity and streamlines the device structure, making project deployment and inventory management easier while offering advantages for customers seeking standardized scanning specifications. -
Optimized for Stable Indoor Operations with Advanced Wireless Technology
With support for Wi-Fi 6E (802.11ax) and 2×2 MU-MIMO, the SM24 delivers seamless and stable performance even in large retail stores, ware houses, and production lines where many devices connect simultaneously, offering exceptional efficiency in high-density AP environments. -
Front-Side NFC for Global Standards
The front-side (LCD-side) NFC supports ISO 14443 A/B, FeliCa, ISO 15693, and 13.56 MHz, ensuring broad compatibility with global NFC standards and enabling stable, efficient contactless workflows. -
Superior Durability for Its Class (IP67 · 1.8m)
Despite being a cost-optimized model, the SM24 maintains robust durability with 1.8m drop resistance (with boots), 2,000 tumbles, and an IP67 rating, ensuring reliable operation even in harsh industrial environments with dust, moisture, and impact delivering strong protection while keeping overall costs efficient.
Specification
| Size | ⓦ77 x ⓗ167 x ⓓ12.9 mm |
|---|---|
| Weight | 240g |
| Display | 6 Inch HD+ |
| CPU | 2.4 GHz Octa-core Qualcomm SM6225 |
| Operating System | Android 16 to 18 |
| Memory | 8/128 GB |
| Data Capture | 2D Imager - CM60E |
| WWAN | 4G: B1/2/3/4/5/7/8/20/28/38/39/40/41 3G: 1/2/3/4/5/8 2G: 850/900/1800/1900 |
| WLAN | IEEE 802.11 a/b/g/n/ac/d/h/i/r/k/v/w/ax; 2x2 MU-MIMO; Wi-Fi 6E (801.11ax) |
| WPAN | Bluetooth v5.3, BLE |
| Battery | 4000mAh(Standard), 6000mAh(Option) Hot-Swap Support |
| Tumble Test | 1M/1,000times (With Boots), 0.5M/1,000times (Without Boots) |
| Drop Test | 1.8M (With Boots), 1.5M (Without Boots) drops to concrete across the operating temperature range per MIL-STD-810H |
| Sealing | IP67 |
