A high-performance industrial rugged computer designed for logistics, distribution, and cold storage environments.
The UL30 has passed up to 6,000 tumbler tests (1M with boots) and 3M drop tests (with boots), and is certified with IP67 waterproof/dustproof protection and MIL-STD-810H military standards.Powered by a 2.7GHz octa-core processor, Wi-Fi 6E, and supporting Android OS versions 14–18, it guarantees high-speed data processing, long-term software compatibility, and regular security updates.
With 8GB RAM, 128GB storage, and a large 6,700mAh battery, it provides the continuous power needed for extended operations.
Additionally, it supports either a 2D imager or a long-range scanner, offering flexible solutions for various work environments.
Highlights
-
High-Performance CPU for Fast Processing and Multitasking
powered by the Qualcomm QCS6490 chipset and a 2.7GHz octa-core processor, delivers exceptional performance and power efficiency.\r\nIt supports Wi-Fi 6E with 2x2 MU-MIMO for fast, stable communication even in congested industrial environments. The integrated Hexagon NPU provides strong AI processing for QCR and image recognition, greatly enhancing operational efficiency. -
Proven Durability Through Thousands of Drop Tests
The UL30 has passed up to 6,000 tumbles from 1 meter (with boots) and 3-meter drops (with boots). With IP67 waterproof and dustproof rating and MIL-STD-810H military-grade shock resistance, it is a truly rugged computer combining both functionality and durability. It can be confidently used in environments where devices are frequently subjected to impacts, such as logistics, manufacturing, and construction sites. -
F Model Specialized for Cold Environments
F (Frozen) model designed for low-temperature environments, operating reliably in conditions ranging from -30°C to 60°C. It can also be safely stored in extreme temperatures from -40°C to 80°C, demonstrating excellent durability. Equipped with a battery optimized for low temperatures, it ensures stable performance and continuous operation even in harsh environments. -
High-Speed, Efficient Wireless Communication with Wi-Fi 6
Wi-Fi 6E utilizes the previously unused 6GHz band, providing a wider frequency range and more high-speed channels. This ensures fast, stable, and low-latency connectivity even in congested network environments without interference. -
Long-Term Software Compatibility and Regular Security Updates
Broad OS support from Android 13 to 15 ensures continuous security and feature updates, allowing the device to remain up-to-date without replacement. This extends the equipment’s lifespan, reduces maintenance costs, and effectively lowers the total cost of ownership (TCO) for users. -
8GB RAM / 128GB Storage for Seamless Multitasking and Data Handling
With 8GB of RAM and 128GB of storage, the device is optimized for high-performance multitasking and large data processing, maximizing stability and work efficiency in industrial environments. -
High-Capacity Battery for Up to 13 Hours of Use
Equipped with a 6,700mAh battery, the device can operate for up to 13 hours without replacement. With hot-swap capability, ongoing tasks can continue uninterrupted without the need to reset the device. -
Flexible Scanner Options
Depending on the work environment, users can choose between a 2D barcode scanner (SE4770) and a Long-Range barcode scanner (SE5800). Enjoy excellent scanning performance from close-range to long-distance applications. -
Accelerate Workplace Automation with NFC
Equipped with NFC functionality, the device enables authentication, asset management, and data transfer through simple contact, enhancing work speed and accuracy while accelerating automation in the workplace. -
Clear Image and Video Capture
Equipped with a 16MP rear camera and PDAF technology, which rapidly and accurately focuses by comparing multiple images, the device delivers clear image and video capture in any environment.
Specification
| Size | ⓦ 88.7 x ⓗ 244.75 x ⓓ 46.19 mm |
|---|---|
| Weight | 530g |
| Display | 5 inch FHD |
| Memory | 8/128 GB |
| CPU | 2.7 GHz Octa-core Qualcomm QCS6790 |
| Operating System | Android 14 to 18 |
| Data Capture | 2D Imager - SE4770 Long Range – SE5800 |
| WWAN | - |
| WLAN | IEEE 802.11 802.11 a/b/g/n/ac/ax/d/e/h/i/j/k/r/V 2X2 MU-MIMO Wi-Fi 6E |
| Battery | 6700mAh Hot-Swap Support |
| Tumble Test | 1M/6,000 times (With Boot), 1M /4,000 times (Without Boot) |
| Drop Test | 3M (With Boot), 2M (Without Boot) drops to concrete across the operating temperature range per MIL-STD-810H |
| Sealing | IP 67 |
