A lineup of rugged computers optimized for users’ diverse work environments.
The UL20 offers four model options—W (Wi-Fi), X (Cellular), F (Frozen), and XF (Frozen & Cellular)—allowing you to choose the optimal configuration for various industrial environments.It has passed up to 6,000 tumbles (1m, with boot) and a 3m drop test (with boot), and is certified with IP67 water and dust resistance as well as MIL-STD-810G military-grade durability, ensuring reliable performance even in harsh working conditions.
Equipped with a 5-inch Full HD display and a 6,700mAh high-capacity battery, the UL20 supports stable, long-duration operation.
Additionally, you can choose between a 2D Imager scanner or a Long-Range scanner, enabling flexible adaptation to diverse work environments.
The UL20 is a truly rugged mobile computer you can rely on across a wide range of industrial applications.
Highlights
-
Proven Durability Through Thousands of Drop Tests
The device has passed up to 4,000 tumbles from 1 meter and 3-meter drops when wearing boots. With IP67 waterproof and dustproof rating and MIL-STD-810G military-grade shock resistance, it is a truly rugged computer combining both functionality and durability. It can be confidently used in environments where devices are frequently subjected to impacts, such as logistics, manufacturing, and construction sites. -
F Model Specialized for Cold Environments
The UL20 offers an F (Frozen) model designed for low-temperature environments, operating reliably in conditions ranging from -30°C to 60°C. It can also be stored safely in extreme temperatures from -40°C to 80°C, demonstrating exceptional durability. Additionally, the FX(Frozen & Cellular) model not only supports cold environments but also enables real-time data transfer and stable connectivity via cellular networks in locations without Wi-Fi, ensuring efficient operations even in harsh industrial conditions. -
High-Capacity Battery for Up to 13 Hours of Use
Equipped with a 6,700mAh battery, the device can operate for up to 13 hours without replacement. With hot-swap capability, ongoing tasks can continue uninterrupted without the need to reset the device. -
Flexible Scanner Options
Depending on the work environment, users can choose from a variety of scanners. From 2D Imagers (SE4750, SE4770) to Long Range scanners (SE4850, SE5800), the device delivers excellent scanning performance from close-range to long-distance applications. -
Multiple Keypad Options
The device offers three keypad options to suit different work environments. The 28-key Numeric keypad is ideal for fast barcode processing, the 35-key Function Numeric keypad is effective for shortcut commands and macro settings, and the 53-key Full Alpha Numeric keypad provides high efficiency for tasks requiring extensive text input. -
Accelerate Workplace Automation with NFC
Equipped with NFC functionality, the device enables authentication, asset management, and data transfer through simple contact, enhancing work speed and accuracy while accelerating automation in the workplace. -
Clear Image and Video Capture
Featuring a 16MP rear camera with an LED flash, the device enables accurate image and video capture even in low-light environments.
Specification
| Size | ⓦ 88.7 x ⓗ 244.75 x ⓓ 46.19 mm |
|---|---|
| Weight | 530g |
| Display | 5 inch FHD |
| Memory | UL20X, UL20F - 4/64GB UL20W - 2/16GB |
| CPU | 2.2 GHz Octa-core |
| Operating System | Android 8.1/9.0/10 |
| Data Capture | 2D Imager – SE4750, SE4770 Long Range – SE5800 |
| WWAN | GSM : B3, B5, B8 / WCDMA : B1, B5, B8 TDD-LTE : B38, B40, B41/ FDD-LTE : B1, B3, B5, B7, B8, B20 |
| WLAN | IEEE 802.11 a/b/g/n/ac/d/e/h/i/k/r/w |
| Battery | 6700mAh Hot-Swap Support |
| Tumble Test | 1M/4,000times (Without Boot) |
| Drop Test | 3M (With Boot), 2M (Without Boot) drops to concrete across the operating temperature range per MIL-STD-810G |
| Sealing | IP 67 |
