View Point
An industrial rugged computer that combines flexible options with high performance and the latest wireless technologies.
Building on the diverse keypad and scanner options of the US20,the US30 features a 2.4GHz octa-core processor, providing faster computation, improved app performance, and enhanced multitasking capabilities.
Additionally, with Wi-Fi 6 support, it ensures stable connectivity without speed degradation even in environments with a large number of connected devices, such as factories and logistics warehouses.
Highlights
-
High-Performance CPU for Fast Processing and Multitasking
The US30 is equipped with a 2.4GHz CPU, enabling stable execution of multiple apps and tasks simultaneously. -
High-Speed, Efficient Wireless Communication with Wi-Fi 6
Wi-Fi 6 offers over 40% improved performance compared to Wi-Fi 5, enabling faster handling of large data volumes. It also provides stable connectivity without speed degradation, even in environments with many connected devices, such as factories or logistics warehouses. -
Long-Term Software Compatibility and Regular Security Updates
Broad OS support from Android 13 to 15 ensures continuous security and feature updates, allowing the device to remain up-to-date without replacement. This extends the equipment’s lifespan, reduces maintenance costs, and effectively lowers the total cost of ownership (TCO) for users. -
Proven Durability Through Thousands of Drop Tests
The US30 has passed 3,000 repeated drops from 1 meter with boots and 2,000 repeated drops from 1 meter without boots, demonstrating outstanding durability and reliability even in harsh environments. It can be confidently used in industries where devices are frequently subjected to impact, such as logistics, manufacturing, and construction sites. -
Multiple Keypad Options
The US30 offers four keypad options. The 30-key Numeric keypad allows for fast barcode processing, while the 38-key and 42-key Function Numeric keypads excel at shortcut commands and macro settings. The 51-key Alpha Numeric keypad enhances text input efficiency. Users can select the keypad that best suits their work environment. -
Wide Range of Scanner Options
Depending on the user environment, you can choose from straight and 45° 2D barcode scanners (SE4770), straight Long-Range barcode scanners (SE5800), or Smart Focus scanners (SE5500). Experience excellent scanning performance from close-range to long-distance applications. -
Wider and Clearer Display
The US30 features an IPS display, offering a wide viewing angle and sharp visuals that accurately present information without color distortion from any angle. This allows users to quickly and precisely interpret the screen, significantly enhancing work efficiency. -
High-Capacity Battery for Up to 13 Hours of Use
Equipped with a 6,700mAh battery, the device can operate for up to 13 hours without replacement. With hot-swap capability, ongoing tasks can continue uninterrupted without the need to reset the device. -
Accelerate Workplace Automation with NFC
Equipped with NFC functionality, the device enables authentication, asset management, and data transfer through simple contact, enhancing work speed and accuracy while accelerating automation in the workplace. -
Clear Image and Video Capture
Featuring a 16MP rear camera, the device utilizes PDAF technology, which compares multiple images to achieve fast and accurate focus. This ensures clear image and video capture in any environment.
Specification
| Size | ⓦ 74 x ⓗ 197.2 x ⓓ 35.3 mm |
|---|---|
| Weight | 2D Imager : 416g Long Range : 450g |
| Display | 4 inch HD |
| Memory | 4/64GB |
| CPU | 2.4 GHz Octa-core |
| Operating System | Android 13 to 15 |
| Data Capture | 2D Imager - SE4770 Long Ranger – SE5800 Smart Focus – SE5500 |
| WWAN | - |
| WLAN | IEEE 802.11 a/b/g/n/ac/d/e/h/i/k/r/w/ax, IPv4, IPv6, 2X2 MU-MIMO |
| Battery | 6700mAh Hot-Swap Support |
| Tumble Test | 1M/3,000times (With Boots), 1M/2,000times (Without Boots) |
| Drop Test | 1.8M (With Boots), 1.5M (Without Boots) drops to concrete across the oprating temperature range per MIL-STD-810G |
| Sealing | IP 65 |
