Rugged computer with four selectable keypads and five barcode scanners
It provides a total of four keypad options, including Numeric 30 keys, Function Numeric 38 keys, 42 keys, and Alpha Numeric 51 keys, perfectly supporting everything from bare fingers to gloved fingers and stylus input.Additionally, with 2D Imager (straight and 45-degree), Long-Range, and Smart Focus barcode scanner options, you can choose the optimal model for your application.
Equipped with a 4-inch WVGA IPS display and Corning Gorilla Glass, it boasts excellent visibility and durability, and its large-capacity 6,700mAh battery provides stable performance even in harsh industrial environments.
Highlights
-
Multiple Keypad Options
The device offers four keypad options. The 30-key Numeric keypad is ideal for fast barcode processing, while the 38-key and 42-key Function Numeric keypads excel at shortcut commands and macro settings. The 51-key Alpha Numeric keypad enhances text input efficiency. Users can select the optimal keypad to suit their specific work environment. -
Wide Range of Scanner Options
Depending on the user environment, you can choose from 2D Imagers (SE4710, SE4750, SE4770) for straight or 45° scanning, the Long-Range SE4850 ERI, or the Smart Focus SE5500. Experience excellent scanning performance from close-up to long-distance applications. -
Wider and Clearer Display
Equipped with an IPS display, the device offers a wide viewing angle and clear visuals, accurately presenting information without color distortion from any angle. This allows users to quickly and precisely interpret the screen, significantly enhancing work efficiency. -
High-Capacity Battery for Up to 13 Hours of Use
Equipped with a 6,700mAh battery, the device can operate for up to 13 hours without replacement. With hot-swap capability, ongoing tasks can continue uninterrupted without resetting the device. -
Optimized Connectivity and Flexibility for Various Work Environments
With dual micro SIM support, the device can utilize two networks simultaneously, enhancing communication reliability and allowing users to manage both work and personal—or domestic and international—needs on a single device. This also helps reduce data costs and overall operational expenses. -
Wide Range of Accessory Compatibility
The device is compatible with approximately 20 types of accessories, including 2-slot cradles, battery chargers, protective boots, trigger handles, and vehicle mounts. It is also compatible with future US series products, offering excellent scalability and operational convenience. -
Accelerate Workplace Automation with NFC
Equipped with NFC functionality, the device enables authentication, asset management, and data transfer through simple contact, enhancing work speed and accuracy while accelerating automation in the workplace. -
Clear Image and Video Capture
Featuring a 16MP rear camera, the device utilizes PDAF technology, which compares multiple images to achieve fast and accurate focus. This ensures clear image and video capture in any environment.
Specification
| Size | ⓦ 74 x ⓗ 197.2 x ⓓ 35.3 mm |
|---|---|
| Weight | - 2D 416g - Long Range 450g |
| CPU | 2.2 GHz Octa-core |
| Operating System | Android 10 |
| Memory | 4/64 GB |
| Wireless Data Communication | A. WWAN : LTE FDD: 800/850/900/1800/2100/2600 (1/3/5/7/8/20); LTE TDD: 1600/2300/2500 (38/40/41); UMTS/HSDPA/HSPA+: 850/900/2100(1/5/8); GSM/GPRS/EDGE: 900/1800 (3/8); B. WLAN : IEEE 802.11 a/b/g/n/ac/d/e/h/i/k/r/w, IPv4, IPv6, MU-MIMO C. WPAN : Class 2, Bluetooth v5.0 with BR/EDR and Bluetooth Low Energy (BLE) Support |
| Data Capture | 2D Imager - SE4710, SE4750, SE4770 Long Ranger – SE4850 ERI Smart Focus – SE5500 |
| WWAN | LTE FDD: 800/850/900/1800/2100/2600 (1/3/5/7/8/20); LTE TDD: 1600/2300/2500 (38/40/41); UMTS/HSDPA/HSPA+: 850/900/2100(1/5/8); GSM/GPRS/EDGE: 900/1800 (3/8); |
| WLAN | IEEE 802.11 a/b/g/n/ac/d/e/h/i/k/r/w, IPv4, IPv6, MU-MIMO |
| Battery | 6700mAh Hot-Swap Support |
| Tumble Test | 1M/1,000times (With Boots), 0.5M/2,000times (Without Boots) |
| Drop Test | 1.8M (With Boots), 1.5M (Without Boots) drops to concrete across the operating temperature range per MIL-STD-810G |
| Sealing | IP 65 |
