View Point
A revolutionary premium performance mobile computer that surpasses all existing performances.
Equipped with Qualcomm's top-of-the-line chipset QCM6490, it enables high-speed data processing at up to 2.7GHz, and dramatically improves productivity and efficiency in the workplace through AI-based image analysis and high-speed barcode scanning functions.It also supports Wi-Fi 6E, 5G, and Android 14 to 18 OS, ensuring long-term software compatibility and regular security updates.
8GB of RAM, 128GB of storage, and up to a 7,000mAh (optional) battery provide powerful work continuity that sets it apart from existing mobile devices.
Finally, with IP68-rated water and dust resistance and MIL-STD-810H military standard certification, this premium industrial mobile computer surpasses existing limitations in every aspect, from functionality to durability.
Highlights
-
High-Speed & Reliable Data Processing
Supporting Wi-Fi 6E, the device delivers data transfer speeds of up to 9.6 Gbps, achieving 40% higher wireless performance compared to Wi-Fi 5. It minimizes speed degradation even when multiple devices transmit data simultaneously and prevents network interference in multi-AP environments, ensuring stable connectivity. Additionally, in areas without Wi-Fi, it supports various mobile networks from 2G to 5G, enabling ultra-fast uploads and downloads while maintaining reliable communication quality even with multiple connected devices. -
Enhanced Work Environment with AI
The SM30, equipped with an AI engine capable of 12 trillion operations per second, significantly improves barcode and QR code scanning speeds. It automatically removes or corrects noise from damaged or blurred barcodes for fast and accurate recognition. Additionally, it can detect and classify defective products or components in real time. All AI processing is performed locally on the device, allowing full AI functionality without the need for an internet connection or cloud server. -
Long-Term Software Compatibility and Regular Security Updates
With long-term support for Android 14 through 18, the device continuously receives security and feature updates, allowing it to stay up-to-date without the need for replacement. This extends the equipment’s lifespan, reduces maintenance costs, and effectively lowers the total cost of ownership (TCO) for users. -
High-Capacity Battery for Up to 24 Hours of Use
Users can choose between a 5,000mAh standard battery and an optional 7,000mAh battery based on their working environment. The 7,000mAh battery supports up to 24 hours of continuous use without replacement, and with hot-swap capability, ongoing tasks can continue uninterrupted without resetting the device. -
8/128GB for Seamless Multitasking and Data Storage
With 8GB RAM and 128GB storage, the device is optimized for high-performance multitasking and large-scale data processing, maximizing reliability and work efficiency in industrial environments. Additionally, the expandable slot supports up to 2TB, allowing seamless management of large data volumes and multiple applications without storage limitations. -
Real-Time Device Management via M3 Mobile’s Proprietary App with BLE Beacon Technology
The device is equipped with BLE beacon functionality and comes preloaded with M3 Mobile’s proprietary Device Locator app. Using beacon signals without any additional setup, the app accurately tracks the real-time location of the device, even when it is powered off. In case of a lost device, a remote sound alert can be triggered for quick retrieval. This feature enhances productivity and operational reliability, especially in environments where multiple devices need to be managed simultaneously. -
Top-Tier Waterproof/Dustproof Rating and Durability Certification
The device has achieved the highest-level IP68 waterproof and dustproof rating. It has also passed more than 29 environmental durability tests, including vibration, shock, high and low temperatures, humidity, dust, salt, and altitude, earning MIL-STD-810H military-grade certification. Equipped with a hard-pack injection-molded battery, it is highly resistant to external impacts and provides stable power supply, further enhancing the overall durability of the device. The hard-pack battery plays a key role in the SM30’s ruggedness and reliability. -
Flexible Scanner Options
Users can choose from Zebra’s 2D Imagers SE4770, or the SE5500 barcode scanner with Smart Focus functionality. All scanners support fast and accurate 1D and 2D barcode recognition. The SE5500, in particular, can scan from as close as 5.6 cm up to 14 meters, enabling rapid and precise barcode capture even in blurred or challenging environments, maximizing work efficiency. -
Clear Image and Video Capture
Featuring a 5MP front camera and a 16MP rear camera, the device utilizes PDAF technology, which compares multiple images to achieve fast and accurate focus. This ensures clear image and video capture in any environment.
Specification
| Size | ⓦ78.5 x ⓗ161.64 x ⓓ17.5 mm |
|---|---|
| Weight | 297g |
| Display | 5.7 Inch FHD |
| Memory | 8/128 GB |
| CPU | 2.7 GHz Octa-core Qualcomm QCM6490 |
| Operating System | Android 14 to 18 |
| Data Capture | 2D Imager - SE4770 Smart Focus – SE5500 |
| WWAN | 5G FR1: n1/2/3/5/7/8/20/28/38/40/41/66/71/77/78; 4G: B1/2/3/4/5/7/8/13/17/20/28/38/39/40/41/42/43/66/71; 3G: 1/2/4/5/8 2G: 850, 900, 1800, 1900 |
| WLAN | IEEE 802.11 a/b/g/n/ac/d/h/i/r/k/v/w/mc/ax; 2x2 MU-MIMO; Wi-Fi 6E (802.11ax); Dual Band Simultaneous; IPv4, IPv6 |
| Battery | 5000mAh(Standard), 7000mAh(Option) Hot-Swap Support |
| Tumble Test | 1M/1,000times (With Boots), 0.5M/2,000times (Without Boots) |
| Drop Test | 1.8M (With Boots), 1.5M (Without Boots) drops to concrete across the operating temperature range per MIL-STD-810H |
| Sealing | IP68 |
